Product Introduction
The NASA500T-1075KWH is a cutting-edge 20-foot containerized Battery Energy Storage System (BESS) designed for industrial and commercial applications. With a rated energy capacity of 1.075MWh and 500kW output power, it enables peak shaving, reduces transformer costs, and delivers a 98.7% conversion efficiency for maximized ROI. Its standardized design supports flexible capacity expansion, while multi-layer safety protocols ensure reliable operation in diverse environments.
High Efficiency: 98.7% system conversion efficiency optimizes ROI.
Scalable Design: Modular architecture for easy capacity expansion.
Robust Safety: BMS + thermal management + fault classification protection.
Smart Monitoring: Real-time system status tracking via TCP/485/CAN/232.
Extreme Durability: 8,000+ cycles @80% DoD and IP55 protection.
| Category | Specification |
|---|---|
| Battery Side | |
| Cell Type | 3.2V 280Ah LFP |
| System Combination | 5×1P240S |
| Rated Energy | 1.075 MWh |
| Voltage Range | 720–850V DC |
| Cycle Life | ≥8,000 cycles @80% DoD |
| Photovoltaic Side | |
| MPPT Channels | 10 |
| MPPT Range | 420–850V |
| AC Side | |
| Output Power | 500 kW |
| Voltage/Frequency | 380/400V, 50Hz |
| System | |
| Cooling Method | Air cooling |
| Fire Protection | Perfluorohexanone + Aerosol |
| Dimensions | 20ft Container |
| Operating Temperature | Charge: 0–55°C; Discharge: -10–60°C |
Q1: What applications does this BESS support?
A: Peak shaving, solar EV charging, microgrids, frequency regulation, and industrial energy arbitrage.
Q2: Can it operate in extreme temperatures?
A: Yes, discharge is supported from -10°C to 60°C.
Q3: What certifications does the system hold?
A: UL1973, IEC62619, UL9540A, TUV, and CE.
Q4: How is safety ensured?
A: Multi-layer protection includes BMS, thermal management, fault classification algorithms, and fire suppression systems.
Q5: What communication protocols are supported?
A: TCP/IP, RS485, CAN, and RS232.
